外觀尺寸: 198mm(W) X 145mm(D) X 30mm(H)
信號主核Main core: FPGA Xinlinx Kintex 7 + GOWIN GW5AT + MIPI PHY (C/D-phy) Chip
MIPI Dual DSI(D-PHY), 4-lane x 2, 2.0Gbps/lane
MIPI Dual DSI(C-PHY), 3-Trio x 2, 1.5Gsps/Trio
支持 MIPI C-PHY v1.1, D-PHY v1.1
支持 DSI V2.2 (V to C / C to V)
Support Video and command mode DSC v1.1
通信介面: High-Speed USB(480Mbps),RS-232C/HDMI Input
內部Internal Memory: 8G-bit NAND Flash Memory + DDR3 8Gbits
外部擴充記憶體External Memory: SD Memory Card, Max 32G-Byte
GPIO: 8ea, I/O level 1.2V~3.6V programmable.
SPI/i2C/TE sync/Qsync support
可編程 VIO/VDD/VCC 3Power +電流測量: +1.0V~ +12V/1A
VSP: +1.0V~+9V/1A；VSN: -1.2V~-9V/1A
VBAT: +1.2V~+9V/1A；支援Sensing
Fixed Power: +15V, +5V
Fixed, +5V/0.5A, +15V/0.5A
